| Receiver Type | Tabletop |
| Mounting Options | Rackmount, Tabletop (with Included Hardware) |
| Rackmount Size | 1 RU (1/2 Rack) |
| Antenna | 2x 1/2 Wave External, BNC (Rear-Mount) |
| Antenna Bias Voltage | 12 to 13 VDC, 150 mA (per Antenna) |
| Number of Audio Channels | 1 |
| Built-In Microphone | No |
| Audio I/O | 1x XLR 3-Pin Male Balanced Output
1x 1/4″ TRS Female Balanced Output |
| Gain Range | -18 to +42 dB (1 dB Steps) |
| Pad | 30 dB |
| Audio Output Level | XLR Output:
+18 dBV (Line Level)
XLR Output:
-12 dBV (Mic Level)
1/4″ Output:
+12 dBV (Consumer Level, Instrument Level) |
| Phantom Power Protection | On 1/4″, XLR Outputs |
| Frequency Response | 30 Hz to 20 kHz ±1 dB (Dependent on Mic) |
| Network I/O | 1x RJ45 (10/100 Mb/s) |
| Network Protocols | DHCP, Manual IP |
| USB Class-Compliant | No USB Connectivity |
| Standalone Audio Interface Capable | No |
| Impedance | XLR Output:
100 Ohms (Balanced) |
| Approximate RF Sensitivity | -98 dBm |
| Adjacent Channel Isolation | >70 dB |
| Spurious | Rejection: >80 dB |
| Power Requirements | AC/DC Power Adapter |
| AC/DC Power Adapter | 15 VDC at 600 mA (Included) |
| Input Power | 100 to 240 VAC, 50 / 60 Hz at 250 mA |
| DC Input Power | 15 VDC at 600mA |
| Display & Indicators | 1x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)
2x Multi-Segment LED (AF Level, Output Level, Peak) |
| Housing | Steel |
| Operating Temperature | 0 to 122°F / -17 to 50°C |
| Storage Temperature | -20 to 165°F / -28 to 73°C |
| Dimensions | 6.7 x 1.7 x 7.8″ / 171 x 44 x 197 mm |
| |
